102 Workshop Manual, TPD 1377E, issue 4
100 Series
Fuel injection pump
To remove and to fit Operation 11-6
Special requirements
Caution: Connections should be blanked off until assembly.
Notes:
For emissions approved engines. If a new fuel injection pump is fitted, shims of the same thickness as the
originals and a pump with the same part number must be fitted.
For emissions approved engines. If the fuel injection pump is put back, it is essential that the fuel
adjustment screw is not altered from the original setting. The maximum No Load Speed should be checked
after assembly.
Torque Nm (lbf ft) kgf m
102-05, 103-07 11 (8) 1,1
103-10 6 (4.4) 0,6
103-13, 103-15, 104-19, 104-22 15 (11) 1,5
