36 Workshop Manual, TPD 1377E, issue 4
100 Series
Cylinder head gasket
To remove and to fit Operation 3-12
Align gasket on dowels, gasket must only be assembled with markings (A1) facing up.
Notes:
Always fit dry.
For emissions approved engines. If the cylinder block, crankshaft, connecting rods or pistons are changed,
the piston height must be checked and the correct thickness gasket used, refer to operation 3-13.
1
