66 Workshop Manual, TPD 1377E, issue 4
100 Series
Timing cover
To remove and to fit Operation 6-2
For crankshaft pulley removal refer to Operation 5-1.
Notes:
Make sure that the governor springs are correctly attached before the timing cover is fitted, see Operation
6-14.
On assembly hold arm clockwise.
After fitting the timing cover, look through the ESOS mounting holeand check that the linkage moves
correctly when the throttle lever on the fuel injection pump is operated.
For emissions approved engines. The fuel adjustment screw should not be altered from original setting.
The Maximum No Load Speed must be checked after assembly.
If a new timing case is fitted, a new emissions label must be fitted.
