20 Workshop Manual, TPD 1377E, issue 4
100 Series
Crankshaft journal diameters
(1) If the diameter is less than this value, the crankshaft must be renewed.
Engine model/Journal type
Journal
No.
Diameter mm (in)
Standard Service limit
102-05
Standard
1 42,964 - 42,975 (1.69150 - 1.69193) 42,90 (1.689)
2 45,948 - 45,959 (1.80897 - 1.80941) 45,90 (1.807)
Undersize 0,25 mm (0.01 in)
1 42,714 - 42,725 (1.68165 - 1.68210) 42,65 (1.679)
2 45,698 - 45,709 (1.79913 - 1.79960) 45,65 (1.797)
Undersize 0,50 mm (0.02 in)
1 42,464 - 42,475 (1.67181 - 1.67224) 42,40 (1.669)
(1)
2 45,448 - 45,459 (1.78930 - 1.78972) 45,40 (1.787)
(1)
103-07
Standard
1, 2 42,964 - 42,975 (1.69150 - 1.69193) 42,90 (1.689)
3 45,948 - 45,959 (1.80897 - 1.80941) 45,90 (1.807)
Undersize 0,25 mm (0.01 in)
1, 2 42,714 - 42,725 (1.68165 - 1.68210) 42,65 (1.679)
3 45,698 - 45,709 (1.79913 - 1.79960) 45,65 (1.797)
Undersize 0,50 mm (0.02 in)
1, 2 42,464 - 42,475 (1.67181 - 1.67224) 42,40 (1.669)
(1)
3 45,448 - 45,459 (1.78930 - 1.78972) 45,40 (1.787)
(1)
103-10
Standard 1, 2, 3 45,964 - 45,975 (1.80960 - 1.81004) 45,90 (1.807)
Undersize 0,25 mm (0.01 in) 1, 2, 3 45,714 - 45,725 (1.79980 - 1.80020) 45,65 (1.797)
Undersize 0,50 mm (0.02 in) 1, 2, 3 45,464 - 45,475 (1.78992 - 1.79035) 45,40 (1.787)
(1)
103-13
Standard 1, 2, 3 57,957 - 57,970 (2.28177 - 2.28228) 57,9 (2.280)
Undersize 0,25 mm (0.01 in) 1, 2, 3 57,707 - 57,720 (2.27192 - 2.27244) 57,6 (2.268)
Undersize 0,50 mm (0.02 in) 1, 2, 3 57,457 - 57,470 (2.26210 - 2.26260) 57,4 (2.260)
(1)
103-15
Standard 1, 2, 3 67,957 - 67,970 (2.67550 - 2.67597) 67,90 (2.6732)
Undersize 0,25 mm (0.01 in) 1, 2, 3 67,707 - 67,720 (2.66563 - 2.66614) 67,65 (2.6634)
Undersize 0,50 mm (0.02 in) 1, 2, 3 67,457 - 67,470 (2.65579 - 2.65630) 67,40 (2.6535)
(1)
104-19, 104-22
Standard 1, 2, 3, 4 67,957 - 67,970 (2.67550 - 2.67597) 67,90 (2.6732)
Undersize 0,25 mm (0.01 in) 1, 2, 3, 4 67,707 - 67,720 (2.66563 - 2.66614) 67,65 (2.6634)
Undersize 0,50 mm (0.02 in) 1, 2, 3, 4 67,457 - 67,470 (2.65579 - 2.65630) 67,40 (2.6535)
(1)
