22 Workshop Manual, TPD 1377E, issue 4
100 Series
Bearing holder
Centre bearing
1 Remove the bearing holder and check it for stepped wear and other damage. If it is excessively damaged
renew.
2 Using the Plastigauge ®, measure the oil clearance between the crankshaft centre journal and the bearing.
If the oil clearance is more than the service limit, renew the bearing or grind the crankshaft centre journal and
use an undersize bearing.
Engine model/Journal No.
Clearance mm (in)
Standard Service limit
102-05
No. 1 0,035 - 0,088 (0.00140 - 0.00350) 0,20 (0.0078)
No. 2 0,039 - 0,092 (0.00154 - 0.00362) 0,20 (0.0078)
103-07
No. 1, 2 0,035 - 0,088 (0.00140 - 0.00350) 0,20 (0.0078)
No. 3 0,039 - 0,092 (0.00154 - 0.00362) 0,20 (0.0078)
103-10
No. 1, 2, 3 0,039 - 0,092 (0.00154 - 0.00362) 0,20 (0.0078)
103-13, 103-15
No. 1, 2, 3 0,044 - 0,102 (0.00173 - 0.00401) 0,20 (0.0078)
104-19, 104-22
No. 1, 2, 3, 4 0,044 - 0,102 (0.00173 - 0.00401) 0,20 (0.0078)
