Workshop Manual, TPD 1377E, issue 4 57
5
100 Series
Crankshaft assembly 5
Crankshaft pulley
To remove and to fit Operation 5-1
Special requirements
Note: Store the key (A1) in a safe place until assembly.
Special tools Torque Nm (lbf ft) kgf m
Description Part number 102-05, 103-07 93 (69) 9,5
Crankshaft pulley remover 21825619
103-10 123 (91) 12,5
103-13, 103-15, 104-19, 104-22 304 (224) 31
