Workshop Manual, TPD 1377E, issue 4 83
7
100 Series
Cylinder block assembly 7
Front bush
To fit Operation 7-1
The bush must be fitted with the chamfered side (A2) into the block first, with the joint (A1) uppermost. To
remove, use the tool from the inside of the cylinder block.
Note: Make sure that the oil way in the bush is aligned with the oil way in the block.
1
2
