Workshop Manual, TPD 1377E, issue 4 79
100 Series
Governor spring
To locate and to check Operation 6-14
The main governor springs are colour coded to assist with identification. The colour code is as follows:
Note: Remember the locations of the start spring (A1) and the governor spring (A2).
Part Number Description Colour Code
198217580 Main Spring Black
198217570 Main Spring Purple
198217320 Main Spring Yellow - green
198217110 Main Spring Silver
1
2
