10 Workshop Manual, TPD 1377E, issue 4
100 Series
Engine lift equipment
Special requirements
Maximum engine weights (dry) with flywheel and housing fitted
Torque Nm (lbf ft) kgf m
Lifting hook bolts (A1) 26 (19) 2,6
Engine model 102-05 103-07 103-10 103-13 103-15 104-19 104-22
Engine build code KN KL KD KH KE KF KR
Max engine weight 79 kg 87 kg 111 kg 164 kg 176 kg 207 kg 220 kg
1
1
