7
84 Workshop Manual, TPD 1377E, issue 4
100 Series
Cylinder block top face
To inspect Operation 7-2
Inspect the cylinder block top face for cracks, damage and distortion in the same way as for the cylinder head,
refer to Operation 3-19.
If outside limit, renew the cylinder block.
Note: For emissions approved engines. If a new cylinder block is fitted, the engine should be tested on an
engine test brake and the fuel adjustment screw set. This procedures is only done by a Perkins approved
dealer. This will ensure that the engine will conform with emissions legislation.
Distortion mm (in)
Standard Service limit
Less than 0,05 (0.002) 0,12 (0.005)
A
1
2
