78 Workshop Manual, TPD 1377E, issue 4
100 Series
Oil pump end float
To check Operation 6-13
Special requirements
Use a feeler gauge to check the end float clearance of the oil pump. Adjust with 0,1. 0,15. 0,2. and 0,5 mm
shims.
Clearance mm (in)
Standard Service limit
0,10 - 0,15 (0.0040 - 0.0060) 0,20 (0.0079)
