Auto shutdown wiring diagram
55 Amp alternator charge lamp
Note: Alternator charge lamp rating: 12V - 2.2W at 850 rev/min.
When the engine is at rest the alternator charge lamp is illuminated via the battery and it extinguishes when
the alternator operates.
The use of a lower wattage bulb than the above will increase the speed at which self excitation occurs upon
initial run up, e.g. a charge lamp with a lower wattage bulb will have a rating of 12V - 1.2W at 1300 rev/min.
Pin number
connector
Wire colour Connection
Red Key Switch - AC
Orange Key Switch - 50
Red / Black Solenoid
Brown Oil Pressure Switch
Blue Water Temperature Switch
Black Ground (earth)
12
3
4 5
6
