Workshop Manual, TPD 1377E, issue 4 65
6
100 Series
Timing case and drive assembly 6
Fuel injection pump
To remove and to fit Operation 6-1
Special requirements
When the shim (A1) is not required, assemble using a 0,5 mm bead of silicone sealant.
Note: Blank off the connections of the fuel injection pump until assembly.
Torque Nm (lbf ft) kgf m
Solenoid 17 (12) 1,7
1
