Workshop Manual, TPD 1377E, issue 4 39
100 Series
Valve and valve springs
To remove and to fit Operation 3-15
Special requirements
Caution: Always wear safety glasses.
Inlet and exhaust seals are different on 103-10 and above:
Inlet: Silver garter spring.
Exhaust: Black garter spring with small "EX" inscribed on garter.
Special tools
Description Part number Description Part number
Valve spring remover 21825663
Stem seal replacer - 103-10, 103-13,
103-15, 104-19, 104-22
21825623
Stem seal replacer - 102-05, 103-07 21825622
This document has been printed from SPI². Not for Resale
