Perkins 103-13 - Crankshaft Pin Diameters

2
Workshop Manual, TPD 1377E, issue 4 21
100 Series
Crankshaft pin diameters
(1) If the diameter is less than this value, the crankshaft must be renewed.
Engine model/Pin type
Diameter mm (in)
Standard Service limit
102-05, 103-07
Standard 34,964 - 34,975 (1.37653 - 1.37697) 34,90 (1.374)
Undersize 0,25 mm (0.01 in) 34,714 - 34,725 (1.36669 - 1.36712) 34,65 (1.364)
Undersize 0,50 mm (0.02 in) 34,464 - 34,475 (1.35685 - 1.35728) 34,40 (1.354)
(1)
103-10
Standard 38,964 - 38,975 (1.53401 - 1.53445) 38,90 (1.531)
Undersize 0,25 mm (0.01 in) 38,714 - 38,725 (1.52417 - 1.52460) 38,65 (1.5216)
Undersize 0,50 mm (0.02 in) 38,464 - 38,475 (1.51433 - 1.51476) 38,40 (1.5118)
(1)
103-13
Standard 43,964 - 43,975 (1.73090 - 1.73130) 43,90 (1.728)
Undersize 0,25 mm (0.01 in) 43,714 - 43,725 (1.72102 - 1.72145) 43,65 (1.719)
Undersize 0,50 mm (0.02 in ) 43,464 - 43,475 (1.71120 - 1.71161) 43,40 (1.709)
(1)
103-15, 104-19, 104-22
Standard 51,964 - 51,975 (2.04582 - 2.04626) 51,90 (2.0433)
Undersize 0,25 mm (0.01 in) 51,714 - 51,725 (2.03598 - 2.03641) 51,65 (2.0335)
Undersize 0,50 mm (0.02 in) 51,464 - 51,475 (2.02614 - 2.02660) 51,40 (2.0236)
(1)
