Workshop Manual, TPD 1377E, issue 4 31
100 Series
Fuel injection pipes / fuel return pipes
To remove and to fit Operation 3-7
Special requirements
Notes:
Be aware of holes in washers (A1).
For emissions approved engines. It is essential that the fuel adjustment screw is not altered from the
original setting.
For emissions approved engines. The maximum No Load Speed must be checked after assembly.
Torque Nm (lbf ft) kgf m
102-05, 103-07, 103-10 22 (16) 2,2
103-13, 103-15, 104-19, 104-22 20 (15) 2,0
1
