6
Workshop Manual, TPD 1377E, issue 4 81
100 Series
Timing cover
To fit Operation 6-16
1 Ensure the oil pin (A1) locates in the hole (A2) in the idler gear.
2 Remove the oil seal protector after the timing cover is fitted. Fit the key onto the crankshaft nose, refer to
Operation 5-1.
3 To fit the crankshaft pulley refer to Operation 5-1.
2
1
