CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (CONT)
Incorrect aileron travel. Aileron control rods not ad- Adjust control rods.
justed properly.
Aileron bellcrank stops not Adjust bellcrank Stops.
adjusted properly.
Correct aileron travel can- Incorrect rigging of aileron Rerig controls.
not be obtained by adjust- cables, control wheel and
ing bellcrank stops. control rod.
Control wheel stops before Incorrect rigging between Rerig controls.
control surfaces reach full control wheel and control
travel. cables.
RUDDER CONTROL SYSTEM
Lost motion between rud- Cable tension too low. Adjust cable tension.
der pedals and rudder.
Linkage loose or worn. Check linkage and tighten
or replace.
Broken pulley. Replace pulley.
Bolts attaching rudder to Tighten bellcrank bolts.
bellcrank are loose.
Excessive resistance to rud- System not lubricated Lubricate system.
der pedal movement. properly.
Rudder pedal torque tube Lubricate torque tube bear-
bearing in need of lubri- ings.
cation.
Cable tension too high. Adjust cable tension.
Pulleys binding or rubbing. Replace binding pulleys
or provide clearance be-
tween pulleys and brackets.
27 - 02 - 00
Page - 27 - 03
Reissued: August 1, 1986
1K2
Trouble Cause Remedy
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
AILERON CONTROL SYSTEM (CONT)
