27 - 02 - 00
Page - 27 - 04
Reissued: August 1, 1986
1K3
CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (cont.)
Excessive resistance to rudder Cables not in place on Install cables correctly. Check
pedal movement. (cont) pulleys cable guards.
Cables crossed or routed Check routing of control
incorrectly. cables.
Rudder pedals not neutral Rudder cables incorrectly Rerig rudder cables.
when rudder is streamlined. rigging.
Incorrect rudder travel. Rudder bellcrank stop Rerig bellcrank stops.
incorrectly adjusted.
Nose wheel contacts stops Rerig nose wheel stops.
before rudder.
Trim control knob moves System not lubricated Lubricate system.
with excessive resistance. properly.
Lost motion between Cable tension too low, Adjust cable tension.
control wheel and stabilator.
Linkage loose or worn. Check linkage and tighten
or replace.
Broken pulley. Replace pulley.
Cables not in place on Install cables correctly.
pulleys.
Resistance to Stabilator System not lubricated Lubricate system.
control movement. properly.
Cable tension too high. Adjust cable tension.
Binding control column. Adjust and lubricate.
Trouble Cause Remedy
PIPER AIRCRAFT
PA-28-236
MAINTENANCE MANUAL
RUDDER CONTROL SYSTEM (CONT.)
RUDDER TRIM CONTROL SYSTEM
STABILATOR CONTROL SYSTEM
