LIST OF ILLUSTRATIONS (cont.)
FIGURE NO. SUBJECT GRID NO.
32-7. Main Wheel Assembly 2C4
32-8. Nose Wheel Assembly 2C6
32-9. Standard Brake Assembly (Cleveland 30-55) 2C8
32-10. Heavy Duty Brake Assembly (Cleveland 30-65) 2C9
32-11. Removal and Installation of Anchor Bolts 2C10
32-12. Brake Disc Minimum Thickness 2C11
32-13. Brake System Installation 2C11
32-14. Brake Master Cylinder (Hand/Parking Brake) 2C13
32-15. Toe Brake Installation 2C15
32-16. Brake Cylinder 10-30 (Toe Brake) 2C16
32-17. Brake Cylinder 17000 (Toe Brake) 2C16
33-1. Strobe Light Connections 2D4
34-1. Pitot/Static System 2D11
37-1. Auxiliary Vacuum Pump Installation 2E12
51-1. Skin Materials and Thickness 2E23
51-1a. Baggage Compartment Inspection Holes Cutout Details 2F1
51-2. Surface Scratches, Abrasions or Ground-in-Dirt 2F5
51-3. Deep Scratches, Shallow Nicks and Small Holes 2F6
51-4. Mixing of Epoxy Patching Compound 2F6
51-5. Welding Repair Method 2F8
51-6. Repairing of Cracks 2F8
51-7. Various Repairs 2F9
51-8. Repair of Stress Lines 2F11
51-9. Repair of Impacted Damage 2F11
52-1. Door Snubber Installation 2F19
55-1. Empennage Group Installation 2G1
55-2. Methods of Securing Control Cables 2G2
55-3. Stabilator Balance 2G2
55-4. Rudder Balance 2G5
56-1. Windshield Installation (Typical) 2G10
56-2. Side Window Installation, Single Pane (Typical) 2G11
57-1. Wing Installation 2G15
57-2. Aileron and Flap Installation 2G20
57-3. Aileron Balance Configuration 2G24
61-1. Typical Nicks and Removal Method 2H4
61-2. Propeller Installation 2H6
61-3. Propeller Governor 2H8
61-4. Adjustment of Propeller Control 2H8
71-1. Engine Installation (PA-28-236) 2I1
71-2. Engine Mount Assembly 2I2
71-3. Cowling Installation (PA-28-236) 2I3
71-4. Carburetor Ice Detection System 2I5
71-5. Carburetor Ice Detector Probe Installation 2I7
71-6 . Rear View of Carburetor Airbox 2I9
73-1. Carburetor 2I13
