Bit depth refers to the color information stored in an image. The
higher the bit depth of an image, the more colors it can store.
Convert the dynamic range. Free conversion between SDR, HDR10 and
HLG is supported.
This menu item is displayed only when Dynamic Range Conversion is
turned on ( ).
Gamma value
This menu item is displayed only when Dynamic Range Conversion is
turned on ( ).
Set output color gamut standard.
This menu item is displayed only when Dynamic Range
Conversion is turned on ( ).
Mapping mode. This menu item is displayed when Dynamic Range is
HDR10.
: On. Luminance overrides Peak Screen Brightness.
: Off. Luminance overrides Max CLL.
Peak luminance. This menu item is displayed when Dynamic Range
is HDR10 or HLG.
Set PGM Edit
Turn on or off PGM edit.
Prerequisites
The device is in switcher mode. In PGM only mode, PGM Edit cannot be set and
turned on by default.
The screen is a common screen or AUX screen and Screen Status is set to .
Menu Orientation
On the main menu screen, scroll to and select Screen > Screen1 > PGM Edit.
Output information (P20)
