EMC limit values and mains filter selection
Explanation on the sizing criterion EMC limit value class:
● See chapter 10.1.3 "Noise Emission of the Drive System"
on page 182
● Calculation formulas for determining the allowed leakage ca‐
pacitances:
See chapter 15.3.6 "Determining the Leakage Capacitance"
on page 272
● The mains filters used have been specifically dimensioned
for Rexroth drive systems. For filters by other manufacturers,
Rexroth cannot guarantee mains interference suppression
with regard to allowed limit values.
● The indicated EMC limit values apply to grounded mains.
Ungrounded mains require additional measures.
The selection tables do not contain all practical applications (e.g., use of
mains filters and mains chokes by several drive systems). For such cases,
mains filters and mains choke can be selected, too:
● See chapter 15.3.1 "Determining the Mains Choke" on page 264
● See chapter 15.3.2 "Determining the Mains Filter" on page 264
8.3.2 Mains Connection of HMV Supply Units
Mains Connection of HMV Supply Units - Additional Components
Use HNL mains choke and HNF mains filter
For interference-free operation of supply units with regeneration
back to the mains (HMVxx.xR), use appropriate HNL mains
chokes and HNF mains filters in the mains connection.
Supply unit Transformer Mains filter Mains choke
DST
(auto)
DLT (isolat‐
ing)
HNF01.1*-
****-R****
HNF01.1*-
****-E****
HNS
02.1
HNL01.1E;
HNL01.1E-
****-S
HNL01.1R;
HNL01.1R-
****-S
HNL 02.1
HMV01.1E-W ■ ■ - ■ - ■ - -
HMV01.1R-W ■ ■ ■ (!) - - - ■ (!) -
HMV02.1R-W ■ ■ - - ■ (!) - - ■ (!)
■ Allowed
■ (!) Must be used
- Not allowed
Tab.8-5: Additional Components Mains Connection
