REXROTH IndraDrive - Mains Connection of HMV01.1 E Supply Units

Mains Connection of HMV01.1E Supply Units
Supply unit Mains chokes Mains filter Explanation EMC limit value class to
be achieved
1)
: Max.
leakage capacitance
C
ab_g
; motor cable
length
HMV01.1E-
W0030
HNL01.1E-0400-
N0051
HNF01.1A-F240-
E0051
Standard combination for axis sys‐
tems with C
y
≤ 2 × 1225 nF
Number of axes ≤ 18
A1: 290 nF;
280 m (f
s
= 8 kHz)
110 m (f
s
= 12 kHz)
Without Reduced performance data; see
Project Planning Manual
HNL01.1E-0400-
N0051
HNF01.1A-M900-
E0051
Standard combination for axis sys‐
tems with C
y
≤ 2 × 2040 nF
Number of axes ≤ 40
A1: 1100 nF;
1,050 m (f
s
= 8 kHz)
270 m (f
s
= 12 kHz)
Without Reduced performance data; see
Project Planning Manual
HNL01.1E-0400-
N0051 with
HNL01.1E-5700-
S0051
Customer-side Standard mains choke connected
in series with current-compensated
mains choke to reduce line-fre‐
quency leakage currents
Not specified
Without Without Not allowed
HMV01.1E-
W0075
HNL01.1E-0200-
N0125
HNF01.1A-F240-
E0125
Standard combination for axis sys‐
tems with C
y
≤ 2 × 1225 nF
Number of axes ≤ 18
A2.2: 290 nF;
280 m (f
s
= 8 kHz)
110 m (f
s
= 12 kHz)
Without Reduced performance data; see
Project Planning Manual
HNL01.1E-0200-
N0125
HNF01.1A-M900-
E0125
Standard combination for axis sys‐
tems with C
y
≤ 2 × 2040 nF
Number of axes ≤ 40
A2.2: 1100 nF;
1,050 m (f
s
= 8 kHz)
270 m (f
s
= 12 kHz)
Without Reduced performance data; see
Project Planning Manual
HNL01.1E-0200-
N0125 with
HNL01.1E-2800-
S0125
Customer-side Standard mains choke connected
in series with current-compensated
mains choke to reduce line-fre‐
quency leakage currents
Not specified
Without Without 1 axis (1 HMD01) A2.1: 40 nF;
40 m (f
s
= 8 kHz)
40 m (f
s
= 12 kHz)
Bosch Rexroth AG DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
110/309
Configuring the Drive System
