4 Brief Description, Usage
4.1 General Information
In terms of "Appropriate Use", cases of operation and applications not men‐
tioned in this chapter are not allowed.
In this context, observe the chapter 8 Configuring the Drive Sys‐
tem, page 93.
4.2 Applications of the Drive System Rexroth IndraDrive
The digital, intelligent drive system Rexroth IndraDrive is the cost-efficient
solution with a high degree of functionality for single-axis and multi-axis drive
and control tasks.
The drive system Rexroth IndraDrive fulfills a large number of drive tasks in
the most varied applications.
Typical applications are the industrial sectors:
● Printing and paper converting
● Packaging and food
● Mounting and handling
● Wood machining
● Machine tools
● Metal forming
● General automation
For these applications there are different device types of graduated perform‐
ance.
4.3 Mains Transformers DST and DLT
DST and DLT transformers are used to transform mains voltages to the al‐
lowed nominal voltages of the devices.
DLT transformers are used to
● prevent overvoltage between outer conductor and ground
● protect other loads against leakage currents
Type Usage
DST
autotransformer
Adjusting voltage range in grounded mains
DLT
isolating transformer
Adjusting voltage range in ungrounded mains
Tab.4-1: Usage of Transformers
As a matter of principle, DLT isolating transformers have to be
used at ungrounded mains.
4.4 Mains Filters HNF, HNK, NFE, HNS02 and NFD
Mains filters reduce radio interference and mains pollution.
DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
Bosch Rexroth AG 47/309
Brief Description, Usage
