REXROTH IndraDrive - 18 Appendix; System Elements - Product Overview, Short Designations

18 Appendix
18.1 System Elements - Product Overview, Short Designations
Short designation System element / product Description
CSB01.1 Control section single-axis Scope of functions BASIC
CDB01.1 Control section double-axis
CSH01.1, CSH01.2,
CSH01.3
Control section single-axis Scope of functions ADVANCED
CSB02.1 Control section single-axis (2nd generation) Scope of functions BASIC
CDB02.1 Control section double-axis (2nd generation)
CSH02.1 Control section single-axis (2nd generation) Scope of functions ADVANCED
CSE02.1 Control section single-axis (2nd generation) Scope of functions ECONOMY
CZ 1.2 Additional capacitor Capacitor with touch guard
DLT Isolating transformer
DST Matching transformer
HAT01 Control unit for motor holding brake Is used for the "Safe braking and holding sys‐
tem"
HAB01 Fan unit Blower to be mounted to certain HMV01 and
HMS01
HAC01 Housing for control sections
HAS01 Basic accessory Accessories for connecting the components
(contact bars, fixing material …)
HAS02 Shield connection Accessory for connecting shielded motor cables
to power sections
HAS03 Control cabinet adapter Accessory for adjusting the mounting depth
HAS04 Capacitor Accessory DC bus capacitors against ground
potential
HAS05 Cables, connectors, adapters Accessories to adjust electrical interfaces
HAS06 Closure coupling, closure fitting, tube piece Connection accessories for liquid cooling
HCS02.1 Drive controller Converter
HCS03.1 Drive controller Converter
HLB01.1C DC bus resistor unit For IndraDrive C
HLB01.1D DC bus resistor unit For IndraDrive M
HLC01.1C DC bus capacitor unit For IndraDrive C
HLC01.1D DC bus capacitor unit For IndraDrive M
HLR01 Braking resistor
HMD01.1 Drive controller Power section, double-axis
HMF01.1 Motor filter
HMS01.1 Drive controller Power section, single-axis
DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
Bosch Rexroth AG 285/309
Appendix
