REXROTH IndraDrive - Mains Connection for HCS03 Converters

Converter Mains chokes Mains filter Explanation EMC limit val‐
ue class to be
achieved
1)
:
Max. leakage
capacitance
C
ab_g
HCS02.1E-
W0070
HNL01.1E-0600-
N0032
NFD03.1-480-055 Standard combination for 1 converter A2.1
HNL01.1E-0600-
N0032
NFD03.1-480-055 Central supply to axis systems
● Type current HMS ≤ W0054
● Type current HMD ≤ W0036
● Type current HCS ≤ W0070
● Sum of type currents ≤ 270
(without mains choke ≤ 120)
● Motor cable length ≤ 120 m (f
s
= 8 kHz)
A2.2: 100 nF
A1: 70 nF
B1: 52 nF
HNL01.1E-0600-
N0032
NFD03.1-480-075 A2.2: 110 nF
A1: 70 nF
B1: 55 nF
HNL01.1E-0600-
N0032
HNF01.1A-M900-
E0051
Central supply to axis systems
● Type current HMS ≤ W0054
● Type current HMD ≤ W0036
● Type current HCS ≤ W0070
● Sum of type currents ≤ 270
● 2 × 330 nF ≤ C
y
● Motor cable length ≤ 900 m (f
s
= 8 kHz)
A2.2: 350 nF
1)
In grounded mains
Tab.8-12: Selection of Mains Connection HCS02
Mains Connection for HCS03 Converters
With HCS03.1E drive controllers, the limit value class A2 (see
"Limit Values for Line-Based Disturbances") can be achieved in
grounded mains when using the listed mains filters HNF01.1A or
HNK01.1A or NFD03.1.
Observe notes in chapter 11 Arranging the Components in the
Control Cabinet , page 189.
Bosch Rexroth AG DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
116/309
Configuring the Drive System
