Project Planning Manual "Rexroth IndraDrive Supply Units and Power Sec‐
tions").
The continuous current of the drive controller should be greater
than the one of the motor. The continuous power of the supply
must be greater than the sum of all average powers of the axes of
the drive system!
14.4.2 Selecting the Connection Technique
For the available power cables and encoder cables, see documentation
"Rexroth Connection Cables".
14.4.3 Notes on Commissioning
For further information, notes on commissioning and supporting
documents (e.g., forms for entering the required data) see firm‐
ware documentation.
Bosch Rexroth AG DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
246/309
Third-Party Motors at Rexroth IndraDrive Controllers
