● Motor connection (with optional motor holding brake and motor tempera‐
ture monitor)
● 24 V control voltage
● DC bus connection
● Module bus connection for cross communication in the case of DC bus
connection with other devices
● Connection for external braking resistor (at HCS devices)
For detailed information on the power sections, see Project Planning
Manual "Rexroth IndraDrive Supply Units and Power Sections".
1.6.3 Control Section
The control section is a separate component which is plugged into the power
section. The control section consists of:
● Basic control section circuit board with interfaces
● Optional modules (only for configurable control sections)
The drive controller is supplied complete with factory-installed (possibly con‐
figured) control section.
Only especially trained staff are allowed to replace control sec‐
tions.
For detailed information on the control sections, see Project Planning
Manual "Rexroth IndraDrive Drive Controllers Control Sections".
DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
Bosch Rexroth AG 25/309
System Presentation
