1) Control of K1, if A10 is not used
2) Drive enable (via input at control section or via master communica‐
tion); see parameter "P-0-4028, Device control word"
3) Twist wires
A10 Emergency stop relay (example of circuit)
Bb1 Readiness for operation of supply unit
Bb Readiness for operation of drive controllers (see control section X31.1
and X31.2)
K1 Integrated mains contactor
K4 Control of drive enable
S1 Emergency stop
S4 Power Off
S5 Power On
S11, S12 Safety door monitor
ZKS DC bus short circuit
Fig.9-16: Control Circuit Without DC Bus Short Circuit (ZKS) for HMV02.1R
Supply Units With Integrated Mains Contactor
9.4.5 Signal Sequences When Switching HMV Supply Units ON and OFF
Switching On
Risk of damage to the supply units when they
are switched on simultaneously!
With 3 or more HMV supply units at common supply mains: Switch on supply
units one after the other with a time interval of at least 0.5 seconds so that
the inrush currents are not added.
In the switch-on sequence of the supply unit, the supplying mains is loaded
with the current I
L_trans_max_on
for the purpose of analysis. During the unloading
process, voltage overshoot can occur at the mains components connected in
the incoming circuit (e.g. mains filters) due to inductances connected in the
incoming circuit, e.g. the leakage inductance of the mains transformer.
