REXROTH IndraDrive - Leakage Capacitances; Leakage Capacitance of Motors

Short designation System element / product Description
VCP20 Operator terminal Variant for assembly
VCP25 Operator terminal Variant for assembly
Tab.18-1: Product Short Designations
18.2 Leakage Capacitances
18.2.1 Leakage Capacitance of Motors
The data of the typical leakage capacitance refer to the total capacitance of
the power connections U, V, W against the motor housing. The tables below
contain excerpts from the technical data of motors:
Leakage Capacitance
Type Leakage capacitance of the component
C
ab
nF
MSM019A-0300-NN-__-___ 0,3
MSM019B-0300-NN-__-___ 0,7
MSM031B-0300-NN-__-___ 0,7
MSM031C-0300-NN-__-___ 1,4
MSM041B-0300-NN-__-___ 1,3
Last modification: 2008-11-20
Tab.18-2: MSM019A-0300-NN, MSM019B-0300-NN
Type Leakage capacitance of the component
C
ab
nF
MSK030B-0900-NN-__-___-____ 0,7
MSK030C-0900-NN-__-___-____ 1,3
MSK040B-0450-NN-__-___-____ 1,3
MSK040C-0450-NN-__-___-____ 2,0
MSK043C-0600-NN-__-___-____ 2,1
MSK050B-0300-NN-__-___-____ 2,1
MSK050C-0300-NN-__-___-____ 2,6
MSK060B-0300-NN-__-___-____ 2,1
MSK060C-0300-NN-__-___-____ 2,1
MSK061B-0300-NN-__-___-____ 1,8
MSK061C-0300-NN-__-___-____ 2,4
MSK070C-0150-NN-__-___-____ 3,8
Last modification: 2008-12-10
DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
Bosch Rexroth AG 287/309
Appendix
