REXROTH IndraDrive - Motors

Title
Rexroth IndraDrive …
Kind of documentation
Document typecode
1)
DOK-INDRV*-…
Material number
R911…
Supply Units, Power Sections
HMV, HMS, HMD, HCS02, HCS03
Project Planning Manual HMV-S-D+HCS-PRxx-EN-P 318790
Drive Controllers
Control Sections CSB01, CSH01,
CDB01
Project Planning Manual CSH********-PRxx-EN-P 295012
Control Sections
CSE02, CSB02, CDB02, CSH02
Project Planning Manual Cxx02******-PRxx-EN-P 338962
Additional Components and Accesso‐
ries
Project Planning Manual ADDCOMP****-PRxx-EN-P 306140
1) In the document typecodes, "xx" is a wild card for the current edition of
the documentation (example: PR01 is the first edition of a Project
Planning Manual)
Tab.1-7: Documentations – Overview
Title Kind of documentation
Document typecode
1)
Material number
R911…
Automation Terminals
Of The Rexroth Inline
Product Range
Application Manual DOK-CONTRL-ILSYSINS***-
AWxx-EN-P
317021
1) In the document typecodes, "xx" is a wild card for the current edition of
the documentation (example: AW01 is the first edition of an Applica‐
tion Manual)
Tab.1-8: Documentations – Overview
Motors
Title
Rexroth IndraDyn …
Kind of documentation
Document typecode
1)
DOK-MOTOR*-…
Material number
R911…
A Asynchronous Motors MAD / MAF Project Planning Manual MAD/MAF****-PRxx-EN-P 295781
H Synchronous Kit Spindle Motors Project Planning Manual MBS-H******-PRxx-EN-P 297895
L Synchronous Linear Motors Project Planning Manual MLF********-PRxx-EN-P 293635
S Synchronous Motors MSK Project Planning Manual MSK********-PRxx-EN-P 296289
T Synchronous Torque Motors Project Planning Manual MBT********-PRxx-EN-P 298798
1) In the document typecodes, "xx" is a wild card for the current edition of
the documentation (example: PR01 is the first edition of a Project
Planning Manual)
Tab.1-9: Documentations – Overview
Bosch Rexroth AG DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
