Type Leakage capacitance of the component
C
ab
nF
MSK070D-0150-NN-__-___-____ 5,0
MSK070E-0150-NN-__-___-____ 6,3
MSK071C-0200-FN-__-___-____ 4,6
MSK071D-0200-FN-__-___-____ 6,9
MSK071E-0200-FN-__-___-____ 8,9
MSK075C-0200-NN-__-___-____
MSK075D-0200-NN-__-___-____ 4,6
MSK075E-0200-NN-__-___-____ 5,8
MSK076C-0300-NN-__-___-____ 6,5
MSK100A-0200-NN-__-___-____ 4,8
MSK100B-0200-NN-__-___-____ 10,3
MSK100C-0200-NN-__-___-____ 12,8
MSK100D-0200-NN-__-___-____ 17,6
MSK101C-0200-FN-__-___-____ 6,2
MSK101D-0200-FN-__-___-____ 13,2
MSK101E-0200-FN-__-___-____ 15,2
MSK103A-0300-NN-__-___-____ 1,5
MSK103B-0300-NN-__-___-____ 2,1
MSK103D-0300-NN-__-___-____ 6,0
MSK131B-0200-NN-__-___-____ 14,3
MSK131D-0200-NN-__-___-____ 27,7
Last modification: 2008-12-10
Tab.18-3: MSK - Leakage Capacitance (Excerpt)
See also Rexroth IndraDyn - Technical Data.
18.2.2 Leakage Capacitance of Power Cables
The power cables (bulk cables) of the "RKL" line by Rexroth have the capaci‐
tances per unit length listed below. The values refer to the sum of the single
capacitances of power cores 1, 2 and 3 against the overall shield.
For power cables of the "RKH" line (hybrid cable of IndraDrive Mi), the value
refers to the power cores L+, L- against the overall shield.
See also Rexroth Connection Cables - Data Sheet Bulk Cables.
