Data Sheet Excerpt- Bulk Cables
Type Cross section of power core Leakage capacitance
mm
2
C
Y_K_typ
nF/m
INK0653 1,0 0,6
INK0650 1,5 0,8
INK0602 2,5 0,7
INK0603 4,0 0,8
INK0604 6,0 0,8
INK0605 10,0 1,0
INK0606 16,0 1,2
INK0607 25,0 1,1
INK0667 35,0 1,2
INK0668 50,0 1,3
Last modification: 2007-11-08
Tab.18-4: INK - Technical Data (Excerpt)
Data Sheet Excerpt- Bulk Cables
Type Cross section of power core Leakage capacitance
C
Y_K_typ
mm
2
nF/m
REH0800 2,5 0,2
Tab.18-5: REH - Technical Data (Excerpt)
Approximate calculation is allowed with the following values:
● Cross section 1 … 6 mm
2
: 1 nF/m
● Cross section 10 … 50 mm
2
: 1.2 nF/m
