REXROTH IndraDrive - Supply Units and Converters

Compact converters Modular inverters Type current Contin. current
I
out_cont_4k
[A]
1)
Peak current
I
out_max_4k
[A]
1)
Nominal motor
power [kW]
2)
- HMS01 W0150 100 150 -
HCS03 - W0210 145 210 75
- HMS01 W0210 145 210 -
- HMS01 W0350 250 350 -
1) At fs = 4 kHz; without overload
2) For standard motor 3 AC 400 V; use of mains choke HNL01; variable
torque
3) Mains connection voltage 3 AC 110 ... 230 V
4) Mains connection voltage 3 AC 200 ... 500 V
Tab.1-4: Type Current and Type Performances
1.7.3 Supply Units and Converters
The order of the following table lines conforms with the continuous power of
the devices.
Compact convert‐
ers
Modular mains
supply
Type current or
performance
Contin. power
"ON" P
DC_cont
[kW]
1)
Peak power
"ON" P
DC_peak
[kW]
1)
Contin. braking
power [kW]
Max. braking
power [kW]
HCS02 - E-W0028 4,2 10 0,15 10
HCS02 - E-W0054 9,1 16 0,35 18
HCS02 - E-W0070 13,3 19 0,5 25
- HMV01 R-W0018 18 45 0,4 36
HCS03 - E-W0070 25 40 opt. opt.
- HMV01 E-W0030 30 45 1,5 36
HCS03 - E-W0100 43 59 opt. opt.
HCS03 - E-W0150 56 89 opt. opt.
- HMV02 R-W0015 15 37,5 0,3 33
- HMV01 R-W0045 45 112 0,4 90
- HMV01 R-W0065 65 162 0,4 130
- HMV01 E-W0075 75 112 2 90
HCS03 - E-W0210 85 124 opt. opt.
- HMV01 E-W0120 120 180 2,5 130
- HMV01 R-W0120 120 180 0 0
opt. Equipment to be optionally ordered
1) With use of mains choke HNL01; at 3 AC 400 V
Tab.1-5: Performance Data of Mains Supply Units
The data of peak power and continuous power show the maximum possible
limit values.
For the actually available performance profiles, see Project Planning
Manual "Rexroth IndraDrive Supply Units and Power Sections" → Chapter of
the respective component → "Technical Data" → "Exemplary Data for Applica‐
tions" → "Performance Profiles".
DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
Bosch Rexroth AG 27/309
System Presentation
