4.14 DC Bus Capacitor Unit HLC01
DC bus capacitor units HLC01 store energy in the DC bus of the drive sys‐
tem.
Type Usage
HLC01.1C In drive systems of the product ranges Rexroth
IndraDrive C and Rexroth IndraDrive M
HLC01.1D In drive systems of the product ranges Rexroth
IndraDrive C and Rexroth IndraDrive M
Tab.4-12: DC Bus Capacitor Units HLC
4.15 Fan Unit HAB01
HAB01 fan units cool specific HMV01 and HMS01 devices.
Type Usage
HAB01.1 At HMS01.1N-W0350 drive controllers
At HMV01.1R-W0120 supply units
Tab.4-13: Usage of HAB01 Fan Unit
4.16 Motor Filters HMF01
HMF01 motor filters
● reduce the rise of the output voltage of drive controllers
● reduce leakage currents of the motor lines
● reduce interference voltage on the motor lines
Type Usage
HMF01.1 At the motor output of HCS drive controllers
Tab.4-14: Usage of HMF01 Motor Filters
4.17 Accessories HAS
The HAS accessories support the operation and combination of components
in the Rexroth IndraDrive system.
4.18 Housing for Control Sections HAC01
Additional components HAC01 are used to
● insert control sections in them
● supply control sections with 24V control voltage
Type Usage
HAC01.1-002-NNN-NN To insert CDB control sections in it
Tab.4-15: HAC01 Type
4.19 Hall Sensor Box SHL
The additional component SHL is used when the commutation setting of line‐
ar motors (e.g., IndraDyn L and LSF) is to be carried out, mechanical move‐
Bosch Rexroth AG DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
52/309
Brief Description, Usage
