1.7 Overview of Type Currents and Type Performances
1.7.1 General Information
To allow you selecting appropriate drive controllers for a multitude of applica‐
tions, the Rexroth IndraDrive product range includes a wide range of type
currents and performances. The table below shows the fundamental data of
drive controllers and supply units.
For detailed technical data, see Project Planning Manual "Rexroth
IndraDrive Supply Units and Power Sections".
1.7.2 Drive Controllers
The order of the following table lines conforms with the peak currents of the
devices.
Compact converters Modular inverters Type current Contin. current
I
out_cont_4k
[A]
1)
Peak current
I
out_max_4k
[A]
1)
Nominal motor
power [kW]
2)
HCS01 -
W0003
3)
3
HCS01 -
W0005
4)
5
HCS01 -
W0006
3)
6
HCS01 -
W0008
4)
8
HCS01 -
W0009
3)
9
HCS02 - W0012 4 12 1,5
- HMD01 W0012 6,9 12 -
HCS01 -
W0013
3)
13
HCS01 -
W0018
4)
18
- HMS01 W0020 12,1 20 -
- HMD01 W0020 12,1 20 -
HCS01 -
W0028
4)
28
HCS02 - W0028 11 28 4,0
- HMS02 W0028 13 28 -
- HMS01 W0036 21,3 36 -
- HMD01 W0036 20 36 -
HCS02 - W0054 22 54 7,5
- HMS01 W0054 35 54 -
- HMS02 W0054 25 54 -
HCS02 - W0070 28 70 11
HCS03 - W0070 45 70 18,5
- HMS01 W0070 42,4 70 -
HCS03 - W0100 73 100 30
- HMS01 W0110 68,5 110 -
HCS03 - W0150 95 150 45
