REXROTH IndraDrive - Additional Components; Additional Components at the DC Bus; General Information

Converter Mains chokes Mains filter Explanation
HCS03.1E-
W0210
HNK01.1A-A075-E0146 Standard combination for 1 converter
Motor cable length ≤ 75 m
HNL01.1E-0170-
N0146
- Standard for operating one drive controller without mains filter
HNL01.1E-0170-
N0146
NFD03.1-480-180 Combination for 1 converter
Motor cable length ≤ 5 m
HNL01.1E-0170-
N0146
HNF01.1A-F240-
E0202
Central supply to axis systems
● Type current HMS ≤ W0150
● Type current HMD ≤ W0036
● Sum of type currents ≤ 270
● 2 × 330 nF ≤ C
y
≤ 2 × 600 nF
● Motor cable length ≤ 240 m (f
s
= 8 kHz)
HNL01.1E-0170-
N0146
HNF01.1A-M900-
E0202
Central supply to axis systems
● Type current HMS ≤ W0150
● Type current HMD ≤ W0036
● Sum of type currents ≤ 270
● 2 × 330 nF ≤ C
y
≤ 2 × 1225 nF
● Motor cable length ≤ 900 m (f
s
= 8 kHz)
HNL01.1E-0170-
N0146 with
HNL01.1E-3400-
S0202
Customer-side Standard mains choke connected in series with current-com‐
pensated mains choke to reduce line-frequency leakage cur‐
rents
Tab.8-13: Selection of Mains Connection HCS03
8.4 Additional Components
8.4.1 Additional Components at the DC Bus
General Information
Converters and supply units basically differ in the following features:
● Braking resistor integrated
● Possible connection for external HLR braking resistor
● Operation of DC bus resistor unit HLB
● Operation of DC bus capacitor unit HLC
● Need of HLL chokes for operation
Bosch Rexroth AG DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
120/309
Configuring the Drive System
