Converter Mains chokes Mains filter Explanation
HCS03.1E-
W0150
HNK01.1A-A075-E0106 Standard combination for 1 converter
Motor cable length ≤ 75 m
HNL01.1E-0240-
N0106
- Standard for operating one drive controller without mains filter
HNL01.1E-0240-
N0106
NFD03.1-480-130 Combination for 1 converter
Motor cable length ≤ 5 m
HNL01.1E-0240-
N0106
HNF01.1A-F240-
E0125
Central supply to axis systems
● Type current HMS ≤ W0070
● Type current HMD ≤ W0036
● Sum of type currents ≤ 270
● 2 × 330 nF ≤ C
y
≤ 2 × 600 nF
● Motor cable length ≤ 240 m (f
s
= 8 kHz)
HNL01.1E-0240-
N0106
HNF01.1A-M900-
E0125
Central supply to axis systems
● Type current HMS ≤ W0070
● Type current HMD ≤ W0036
● Sum of type currents ≤ 270
● 2 × 330 nF ≤ C
y
≤ 2 × 1225 nF
● Motor cable length ≤ 900 m (f
s
= 8 kHz)
HNL01.1E-0240-
N0106 with
HNL01.1E-2800-
S0125
Customer-side Standard mains choke connected in series with current-com‐
pensated mains choke to reduce line-frequency leakage cur‐
rents
