REXROTH IndraDrive - Drive Controllers HCS02; Drive Controllers HCS03; Components KCU, KSM, KMS

– CSB02, CSH02, CDB02, CSE02: ≥ MPx18
Type Usage
CSH
Advanced
In HMS01, HMS02, HCS02, HCS03 drive controllers
CSB
BASIC - single-axis
In HMS01, HMS02, HCS02, HCS03 drive controllers
CSE
ECONOMY - single-axis
In HMS01, HMS02, HCS02, HCS03 drive controllers
CDB
BASIC - double-axis
In HMD01 drive controllers
Tab.4-6: Usage of Control Sections
4.9 Drive Controllers HCS02
HCS02 drive controllers control single axes.
Type Usage
HCS02 ● Have a power output to operate a motor
● Power range: 1.5 kW to 11 kW
Tab.4-7: Usage of HCS02 Drive Controllers
4.10 Drive Controllers HCS03
HCS03 drive controllers control single axes.
Type Usage
HCS03 ● Have a power output to operate a motor
● Power range: 18.5 kW to 75 kW
Tab.4-8: Usage of HCS03 Drive Controllers
In their standard design -NNNV, HCS03 drive controllers are not
regenerative.
For applications where regenerative power is generated, use
HCS03.1 of the -NNBV design and HLR braking resistors.
4.11 Components KCU, KSM, KMS
Type Usage
KCU01 Drive connection box to connect KSM01/KMS01 to HMV supply units
or HCS converters
KCU02 Drive connection box to connect KSM02/KMS02 to HMV supply units
or HCS converters
Bosch Rexroth AG DOK-INDRV*-SYSTEM*****-PR06-EN-P
Rexroth IndraDrive Drive Systems with HMV01/02 HMS01/02, HMD01, HCS02/03
50/309
Brief Description, Usage
