8.5.2 Power Section - Control Section
Control section
Power section
HMS01 HMS02 HMD01 HCS02 HCS03 HCS04.2
CSH01.1C
1)
■ ■ - ■ ■ -
CSH01.2C
1)
■ ■ - ■ ■ -
CSH01.3C
1)
■ ■ - ■ ■ ■
CSB01.1N
2)
■ ■ - ■ ■ ■
CSB01.1C
1)
■ ■ - ■ ■ ■
CDB01.1C
1)
- - ■ - - -
CSH02.1B
4)
■ ■ - ■ ■ -
CSB02.1A
3)
■ ■ - ■ ■ ■
CSB02.1B
4)
■ ■ - ■ ■ ■
CSE02.1A
3)
■ ■ - ■ ■ ■
CDB02.1B
4)
- - ■ - - -
■ Allowed
- Not allowed
1) Control section can be configured
2) Control section cannot be configured
3) Basic scope
4) Extended scope
Tab.8-19: Combination Control Section - Power Section
Do not exceed maximum number of plug-in actions!
For a drive controller, the control section mustn't be mounted and
dismounted more than a maximum of 20 times. If this number is
exceeded, the electrical data of the internal connection can be
above the specified minimum requirements. This can cause mal‐
function of the drive controllers.
8.5.3 Control Section - Firmware
For scopes of functions and configurations of firmware versions, see Func‐
tional Description of corresponding firmware version in chapter "Reference
Documentations".
Control section type
1)
Firmware version
CSB01 . 1 N -FC As of MPB-02VRS
CSB01 . 1 N -AN As of MPB-02VRS
CSB01 . 1 C As of MPB-02VRS
CDB01 . 1 C As of MPD-02VRS
CSH01 . 1 C As of MPH-02VRS
CSH01 . 2 C As of MPH-04VRS to MPH-05VRS
