Short designation System element / product Description
HMS02.1 Drive controller Power section, single-axis
HMV01.1E Supply unit Supply unit, infeeding
HMV01.1R Supply unit Supply unit, infeeding and regenerative
HMV02.1R Supply unit Supply unit, infeeding and regenerative
HMV02.1E Supply unit Supply unit, infeeding
HNF01.1 Mains filter
HNL01.1 Mains choke Designs for infeeding systems (E)
Regenerative systems (R)
in current-compensated design
HNL02.1 Mains choke Mains choke with housing for control cabinet
mounting
HNS02.1 Mains filter Mains filter with integrated switch-disconnector
and motor circuit breaker
HNK01.1 Mains filter Mains filter with integrated mains choke, variant
for mounting
KCU01 Drive connection box Additional component of IndraDrive Mi product
range, to connect KSM01 or KMS01 to HMV
supply units or HCS converters
KCU02 Drive connection box Additional component of IndraDrive Mi product
range, to connect KSM02 or KMS02 to HMV
supply units or HCS converters
KSM01
KSM02
Motor-integrated servo drive Motor-integrated servo drive of IndraDrive Mi
product range
KMS01
KMS02
Near motor servo drive Near motor servo drive of IndraDrive Mi product
range
MPB Firmware Scope of functions BASIC
MPD Firmware Scope of functions BASIC, double-axis
MPH Firmware Scope of functions ADVANCED
MSK Synchronous motor
NFD03.1 Mains filter
RKL Ready-made cable Ready-made motor power cable
RKS Ready-made cable Ready-made control cable
RKG Ready-made cable Ready-made encoder cable
RKH Ready-made cable System cable of IndraDrive Mi product range
VCP01 Comfort operator terminal Variant to be plugged on
VCP02 Operator terminal Variant for assembly
VCP05 Operator terminal Variant for assembly
VCP08 Operator terminal Variant for assembly
