Converter Mains chokes Mains filter Explanation
HCS03.1E-
W0070
HNK01.1A-A075-E0050 Standard combination for 1 converter
Motor cable length ≤ 75 m
HNL01.1E-0571-
N0050
- Standard for operating one drive controller without mains filter
HNL01.1E-0571-
N0050
NFD03.1-480-055 Combination for 1 converter
Motor cable length ≤ 5 m
HNL01.1E-0571-
N0050
HNF01.1A-F240-
E0051
Central supply to axis systems
● Type current HMS ≤ W0054
● Type current HMD ≤ W0036
● Sum of type currents ≤ 270
● 2 × 330 nF ≤ C
y
≤ 2 × 600 nF
● Motor cable length ≤ 240 m (f
s
= 8 kHz)
HNL01.1E-0571-
N0050
HNF01.1A-M900-
E0051
Central supply to axis systems
● Type current HMS ≤ W0054
● Type current HMD ≤ W0036
● Sum of type currents ≤ 270
● 2 × 330 nF ≤ C
y
≤ 2 × 1225 nF
● Motor cable length ≤ 900 m (f
s
= 8 kHz)
HNL01.1E-0400-
N0051 with
HNL01.1E-5700-
S0051
Customer-side Standard mains choke connected in series with current-com‐
pensated mains choke to reduce line-frequency leakage cur‐
rents
