Device K
[mm]
L
[mm]
M
[mm]
P
[mm]
R
[mm]
Notes
HCS03.1E-W0210 250 466 50 13 7
HMV01.1E-W0030 100 466 25 13 7
HMV01.1E-W0075 200 466 25 13 7
HMV01.1E-W0120 300 466 25 13 7
HMV01.1R-W0018 125 466 25 13 7
HMV01.1R-W0045 200 466 25 13 7
HMV01.1R-W0065 300 466 25 13 7
HMV01.1R-W0120 300 466 25 13 7
HMV02.1R-W0015 100 378 25 13 7
HMS01.1N-W0020 0 466 25 13 7
HMS01.1N-W0036 0 466 25 13 7
HMS01.1N-W0054 0 466 25 13 7
HMS01.1N-W0070 50 466 25 13 7
HMS01.1N-W0150 100 466 25 13 7
HMS01.1N-W0210 150 466 25 13 7
HMS01.1N-W0350 300 466 25 13 7
HMS02.1N-W0028 0 378 25 13 7
HMS02.1N-W0054 0 378 25 13 7
HMD01.1N-W0012 0 466 25 13 7
HMD01.1N-W0020 0 466 25 13 7
HMD01.1N-W0036 0 466 25 13 7
HNL02.1 100 378 20 13 7
HNS02.1 0 378 55 13 7
HLB01.1C 0 378 32,5 13 7
HLB01.1D 50 466 25 13 7
HLC01.1C-01M0 0 378 25 13 7
HLC01.1C-02M4 0 378 25 13 7
HLC01.1D-05M0 0 466 25 13 7
Tab.11-2: Boring dimensions
Ground the housings of the devices!
1. Connect the bare metal back panel of the device in conductive form to
the mounting surface in the control cabinet.
2. Use the supplied mounting screws and fix the screws with a tightening
torque of typically 6 Nm.
3. Connect the mounting surface of the control cabinet in conductive form
to the equipment grounding system.
