2-445-010 PTr:Std:2Sid:S3 *ENG [1 to 100 / 16 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-445-011 PTr:Low:1:S3 *ENG [1 to 100 / 35 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-445-012 PTr:Low:2:S3 *ENG [1 to 100 / 28 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-445-013 PTr:Std:1Sid:S4 *ENG [1 to 100 / 32 / 1 /step]
139 mm > S4 (Paper width)
2-445-014 PTr:Std:2Sid:S4 *ENG [1 to 100 / 39 / 1 /step]
139 mm > S4 (Paper width)
2-445-015 PTr:Low:1:S4 *ENG [1 to 100 / 35 / 1 /step]
139 mm > S4 (Paper width)
2-445-016 PTr:Low:2:S4 *ENG [1 to 100 / 31 / 1 /step]
139 mm > S4 (Paper width)
2446 [Plain2: LE Correct] DFU
Plain 2: Leading Edge Correction
Adjusts the correction to the paper transfer roller current or discharge plate DC at the
paper leading edge of the plain 2 paper in each mode. SP2440 and SP2441 are
multiplied by these SP values.
Std: 260 mm/sec, Low: 85mm/sec
• The paper leading edge area can be adjusted with SP2447.
5. System Maintenance Reference
326
