2501 [Thick1: Bias]
Adjusts the DC voltage of the discharge plate for thick 1 paper.
Middle: 182 mm/sec, Low: 85 mm/sec
2-501-001 SepaDC:MidSpd:1st *ENG [0 to 6000 / 2000 / 10 -V /
step]
2-501-002 SepaDC:MidSpd:2nd *ENG
2-501-003 SepaDC:LowSpd:1st *ENG
2-501-004 SepaDC:LowSpd:2nd *ENG
2502 [Thick 1: Bias: BW]
Adjusts the current for the paper transfer roller for thick 1 paper in black-and-white
mode.
Middle: 182 mm/sec, Low: 85 mm/sec
2-502-001 PTr:MidSpd:1st *ENG [0 to 230 / 15 / 1 – A /step]
2-502-002 PTr:MidSpd:2nd *ENG Not used
2-502-003 PTr:LowSpd:1st *ENG [0 to 230 / 9 / 1 – A /step]
2-502-004 PTr:LowSpd:2nd *ENG [0 to 230 / 12 / 1 – A /step]
2507 [Thick 1: Bias: FC]
Adjusts the current for the paper transfer roller for thick 1 paper in full color mode.
Middle: 182 mm/sec, Low: 85 mm/sec
2-507-001 PTr:MidSpd:1st *ENG [0 to 230 / 24 / 1 – A /step]
2-507-002 PTr:MidSpd:2nd *ENG Not used
2-507-003 PTr:LowSpd:1st *ENG [0 to 230 / 12 / 1 – A /step]
2-507-004 PTr:LowSpd:2nd *ENG [0 to 230 / 18 / 1 – A /step]
5. System Maintenance Reference
336
