Ricoh Aficio SP C440DN

4. Open the left cover [A].
5. Turn the green lever counterclockwise ( ), and then slowly open the inner cover ( ).
6. Remove the securing pin, as shown, from the transfer unit. Pinch it ( ), and then pull it
out ( - ).
2. Installation
34
