2-716-015 PTr:Low:1:S4 *ENG [1 to 100 / 37 / 1 /step]
139 mm > S4 (Paper width)
2-716-016 PTr:Low:2:S4 *ENG [1 to 100 / 41 / 1 /step]
139 mm > S4 (Paper width)
2721 [MThick:LE Correct] DFU
Standard: 260 mm/sec, Low: 85 mm/sec
Adjusts the correction to the paper transfer roller current at the paper leading edge in
each mode. SP2703 and SP2707 are multiplied by these SP values.
• The paper leading edge area can be adjusted with SP2722.
2-721-001 PTr:Std:1 *ENG [0 to 995 / 100 / 5% /step]
2-721-002 PTr:Std:2 *ENG
2-721-003 PTr: Low: 1st *ENG
2-721-004 PTr: Low: 2nd *ENG
2-721-005 SepaDC:Std:1st *ENG
2-721-006 SepaDC:Std:2nd *ENG
2-721-007 SepaDC:Low:1st *ENG
2-721-008 SepaDC:Low:2nd *ENG
2722 [MThick:SW Tmng:LE] DFU
Standard: 260 mm/sec, Low: 85 mm/sec
Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge plate at
the paper leading edge between the erase margin area and the image area.
Engine SP Mode Tables - SP2000
367
