2-722-001 PTr:Std:1 *ENG [0 to 50 / 0 / 2mm /step]
2-722-002 PTr:Std:2 *ENG
2-722-003 PTr: Low: 1st *ENG
2-722-004 PTr: Low: 2nd *ENG
2-722-005 SepaDC:Std:1st *ENG
2-722-006 SepaDC:Std:2nd *ENG
2-722-007 SepaDC:Low:1st *ENG
2-722-008 SepaDC:Low:2nd *ENG
2723 [MThick:TE Correct] DFU
Standard: 260 mm/sec, Low: 85 mm/sec
Adjusts the correction to the paper transfer roller current for the paper trailing edge in
each mode. SP2703 and SP2707 are multiplied by these SP values.
• The paper trailing edge area can be adjusted with SP2724.
2-723-001 PTr:Std:1 *ENG [0 to 995 / 100 / 5% /step]
2-723-002 PTr:Std:2 *ENG
2-723-003 PTr: Low: 1st *ENG
2-723-004 PTr: Low: 2nd *ENG
2-723-005 SepaDC:Std:1st *ENG
2-723-006 SepaDC:Std:2nd *ENG
2-723-007 SepaDC:Low:1st *ENG
2-723-008 SepaDC:Low:2nd *ENG
2724 [MThick:SW Tmng:TE] DFU
Standard: 260 mm/sec, Low: 85 mm/sec
Adjusts the bias/voltage switch timing of the paper transfer roller/discharge plate at
the paper trailing edge between the erase margin area and the image area.
5. System Maintenance Reference
368
