2-764-010 PTr:Std:2Sid:S3 *ENG [1 to 100 / 23 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-764-011 PTr:Low:1:S3 *ENG [1 to 100 / 37 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-764-012 PTr:Low:2:S3 *ENG [1 to 100 / 39 / 1 /step]
165 mm > S3 size ≥ 139 mm (Paper
width)
2-764-013 PTr:Std:1Sid:S4 *ENG [1 to 100 / 7 / 1 /step]
139 mm > S4 (Paper width)
2-764-014 PTr:Std:2Sid:S4 *ENG [1 to 100 / 43 / 1 /step]
139 mm > S4 (Paper width)
2-764-015 PTr:Low:1:S4 *ENG [1 to 100 / 37 / 1 /step]
139 mm > S4 (Paper width)
2-764-016 PTr:Low:2:S4 *ENG [1 to 100 / 41 / 1 /step]
139 mm > S4 (Paper width)
2771 [SP 1:LE Correct] DFU
Special 1 Paper: Leading Edge Correction
Adjusts the correction to the paper transfer roller current at the paper leading edge in
each mode. SP2753 and SP2757 are multiplied by these SP values.
Standard: 260 mm/sec, Low: 85 mm/sec
• The paper leading edge area can be adjusted with SP2772.
5. System Maintenance Reference
376
