2-814-016 PTr:Low:2:S4 *ENG [1 to 100 / 25 / 1 /step]
139 mm > S4 (Paper width)
2821 [SP 2:LE Correct] DFU
Special 2 Paper: Leading Edge Correction
Adjusts the correction to the paper transfer roller current at the paper leading edge in
each mode. SP2803 and SP2807 are multiplied by these SP values.
Middle: 182 mm/sec, Low: 85 mm/sec
• The paper leading edge area can be adjusted with SP2822.
2-821-001 PTr:Mid:1 *ENG [0 to 995 / 100 / 5%/step]
2-821-002 PTr:Mid:2 *ENG
2-821-003 PTr: Low: 1st *ENG
2-821-004 PTr: Low: 2nd *ENG
2-821-005 SepaDC:Mid:1st *ENG
2-821-006 SepaDC:Mid:2nd *ENG
2-821-007 SepaDC:Low:1st *ENG
2-821-008 SepaDC:Low:2nd *ENG
2822 [SP 2:SW Tmng:LE] DFU
Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge plate at
the paper leading edge between the erase margin area and the image area.
Middle: 182 mm/sec, Low: 85 mm/sec
5. System Maintenance Reference
386
